- Features
- Torque: 12.5–250 ft-lb
- Torque Accuracy: ±2% CW and ±3% CCW, 20–100% of full scale
- Angle Accuracy: ±1% of Reading, ±1° @ Angular Velocity >10°/Sec <180°/Sec
- Angle range: 0–360°
- Six measurement modes (ft-lb, in-lb, Nm, Kgcm, dNm, angle)
- Dual progressive LEDs allow user to see active torque at various work positions; enables user to anticipate torque and slow down as they get closer to desired torque level
- Torque-then-angle allows the user to torque fasteners and then switch to angle without removing the torque wrench from the fastener
- Textured grip offers a comfortable, non-slip surface
- Flared end prevents your hand from slipping off during high-leverage applications
- Ratchet mechanism features Snap-on® Dual 80® Design—only 4.5° of ratchet arc
- Cycle counter to ensure how many fasteners have been torqued
- Unique design offers a streamlined shape with a knurled, non-slip grip—important when working in oily/greasy environments
- Low-profile buttons protect against accidental activation
- Protected end cap design with solid brass contacts prevents accidental loosening and ensures continuity
- Highly configurable ten presets with the ability to customize numerous functions (sleep mode, LCD display, calibration, etc.) and store up to 50 records
- Torque then angle allows the user to torque fasteners and then switch to angle without removing the torque wrench from the fastener
- Large LCD screen numbers become larger and bolder during active torque making it easier to read during use
- Four alert modes (LCD, Dual LED, Audible, Vibratory)
- Features an internal translation feature that allows the user to select a language for the LCD to display (English, French, German or Spanish)
- Long battery life: 80 hours continuous use
- Uses (3) AA alkaline batteries (included)
- Two year warranty
- Specifications
-
| Range, ft-lb |
12.5–250 |
| Range, in-lb |
150–3,000 |
| Gear Action |
4.5° |
| Color |
Chrome |
| Country Of Origin |
USA |
| Storage Case |
PBATECH250B |
| Gear Teeth |
80 |
| Battery, Type (qty) |
AA Alkaline (3) |
| Head Depth, inches |
3/4 |
| Length, inches |
26.7 |
| Flex Joint Repair Kit |
RKRSX936JT |
| Head Width, inches |
1-5/8 |
| Range, N•m |
16.9–339 |
| Ratchet Service Kit |
RKRS80A |
| Head Type |
Sealed Flex Head |
| Square Drive, inches |
1/2 |
| Weight (without batteries), lb (kg) |
4.35 (1.97) |
